Detail Phase Detector Hioki PD3129 Original
Phase Detector Hioki PD3129 OriginalBrand : Hioki
Made in Japan
Hioki’s non-contact voltage detection and measurement technology places efficiency and safety as priority considerations with the goal of protecting customers that need to conduct on-site electrical work as part of renovations and expansions of manufacturing plants and buildings. Model PD3129 is a non-contact phase rotation meter that detects the phase of electrical current flow within insulated wires without using metallic contact voltage clips. The green arrow indicates normal phase, which can be useful for visual reports that document the proper completion of electrical work. CAT III 600 V
Key Features:
Simply clip clamps onto wire insulation • Green LED arrow clearly shows phase direction, perfect for visual reports • Rotating LED indicator shows the phase sequence for a 3-phase power supply at a glance • Intermittent beeps signal positive phase; continuous tone signals reverse phase • Magnetic base allows the instrument to be secured on a distribution panel
Specs:
* Functions: Phase detection (positive and negative)
* Voltage detection method: Static induction
* Voltage range: 70 to 600 V AC (50/60 Hz) (sine wave,continuous input)
* Frequency range: 45 Hz to 66 Hz
* Object to be connected: 2.4 mm (0.09 in) to 17 mm (0.67 in) of insulated wiring
* Display: Phase detection :Positive ; 4 LEDs lit in clockwise order and the buzzer sounds intermittently, green arrow lights up
Negative ; 4 LEDs lit in counterclockwise order and the buzzer sounds continuously
* Battery check function: Power ON lamp: lights up (Power ON), blinks (Battery LOW)
* Auto power off: Auto shut off if no activity is detected after power is turned ON for 15 minutes
* Power supply: R6P (AA) manganese battery ×2, Continuous use: 70 hr
* Dimensions and mass70 mm W × 75 mm H × 30 mm D, 200 g, Cord length : 0.7 m
* Accessories: Carrying case ×1, Strap ×1, Spiral tube ×1, Instruction manual ×1, R6P (AA) battery ×2
