ASROCK MOTHERBOARD Intel Gen Z690 mATX Z690 PG Velocita (DDR5)

Detail ASROCK MOTHERBOARD Intel Gen Z690 mATX Z690 PG Velocita (DDR5)

Terima kasih Sudah berkunjung di Kurnia Abadi Semesta.
Demi kenyamanan bersama terkait harga, stock, warna, dll, harap konfirmasi terlebih dahulu sebelum order.
Terima kasih

Z690 PG Velocita

Supports 12th Gen Intel® Core™ Processors (LGA1700)
17 Phase SPS Dr.MOS Power Design
Supports DDR5 6400MHz (OC)
1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 PCIe 3.0 x16
2 PCIe 3.0 x1
Graphics Output Options: HDMI, DisplayPort
Realtek ALC1220 7.1 CH HD Audio Codec
Nahimic Audio
6 SATA3
1 Blazing M.2 (PCIe Gen5 x4)
2 Hyper M.2 (PCIe Gen4 x4)
1 Ultra M.2 (PCIe Gen3 x4 & SATA3)
1 USB 3.2 Gen2x2 Front Type-C
2 USB 3.2 Gen2 (Rear Type A+C)
10 USB 3.2 Gen1 (6 Rear, 4 Front)
Killer E3100 2.5G LAN, Intel® Gigabit LAN
Killer AX1675 802.11ax (WiFi 6E) + Bluetooth
Lightning Gaming Ports
ASRock Graphics Card Holder

Specifications :
Unique Feature
ASRock USB 3.2 Gen2
- ASRock Front Panel Type-C USB 3.2 Gen2x2 Header (20 Gb/s)
- ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)
- ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s)
ASRock Super Alloy
- XXL Aluminum Alloy Heatsink
- Premium Power Choke
- 60A SPS (Smart Power Stage)

CPU
- Supports 12th Gen Intel® Core™ Processors (LGA1700)
- Digi Power design
- 17 Power Phase design
- Supports Intel® Hybrid Technology
- Supports Intel® Turbo Boost Max 3.0 Technology
- Supports ASRock Hyper BCLK Engine V

Memory
- Dual Channel DDR5 Memory Technology
- 4 x DDR5 DIMM Slots
- Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC)*
- Max. capacity of system memory: 128GB
- Supports Intel® Extreme Memory Profile (XMP) 3.0
- 15μ Gold Contact in DIMM Slots

Slots
CPU:
- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
- 1 x PCIe 4.0 x16 Slot (PCIE3), supports x4 mode*
- 1 x PCIe 3.0 x16 Slot (PCIE5), supports x2 mode*
- 2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE4)*
- 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVi (Integrated WiFi/BT)

OS
- Microsoft® Windows® 10 64-bit / 11 64-bit

Gambar produk
