SCANNER DOKUMEN PLUSTEK SmartOffice PL4080 Automatic Document Feeder (ADF) & Flatbed

Detail SCANNER DOKUMEN PLUSTEK SmartOffice PL4080 Automatic Document Feeder (ADF) & Flatbed

SCANNER DOKUMEN PLUSTEK SmartOffice PL4080 Automatic Document Feeder (ADF) &
Flatbed





Spesifikasi Hardware

Type; Automatic Document Feeder (ADF) & Flatbed

Image Sensor; CIS x 2 (duplex)

Optical Resolution; 600 dpi




Hardware Resolution

* Flatbed: 600 x 1200 dpi
* ADF: 600 x 600 dpi




ADF Capacity

* 50 sheets (A4/Letter, 70 g/㎡ or 18 lb.), Max. thickness under 5mm (0.2″).
* 20 sheets (Business Card)

Note: Maximum ADF capacity varies, depending upon paper weight.




Scanning Speed

* ADF Speed: 40 ppm (200 dpi, all color mode, A4 Portrait)
* Flatbed Speed: 3,5 sec (200 dpi, greyscale mode, A4)

Note: Hasil data bisa berbeda tergantung dari spesifikasi komputer.




Scanning Area (W x L)

Flatbed:

* Max. 216 x 297 mm (8.5” x 11.69”)
* Min. 12.7 x 12.7 mm (0.5” x 0.5”)
* Scan : Kartu Nama, A5, Kuarto, Letter & A4

ADF:

* Max. 220 x 356 mm (8.66” x 14”)
* Min. 12.7 x 12.7 mm (0.5” x 0.5”)
* Scan : Kartu Nama, A5, kuarto, Letter, A4, Folio (F4) & Legal




Acceptable Paper Sizes (W x L)

Flatbed:

* Max. 216 x 297 mm (8.5” x 11.69”)
* Min. 12.7 x 12.7 mm (0.5” x 0.5”)

ADF:

* Max. 220 x 356 mm (8.66” x 14”)
* Min. 90 x 114 mm (3.55” x 4.5”)




Acceptable Paper Weight (Thickness); 50 to 120 g/㎡ (14 to 32 lb.)

Daily Duty Scan ( Sheets ); 3.000

Roller Lifetime (Scans); 100.000

Pad Lifetime (Scans); 50.000

Action Button; Scan、PDF、Custom

Power Supply; 24Vdc/0.75 A

Interface; USB 2.0 x 1

Net Weight; 3.98 Kgs (8.77 Lbs.)

Dimensions (W x D x H); 418 x 326 x 101 mm (16.45″ x 12.83″ x 4″)

Protocol; TWAIN Compliant

OS; Windows XP / Vista / 7 / 8 / 10 / 11

Hardware Requirements

* Pentium IV 3.2 GHz processor or faster CPU
* CD-ROM Drive
* One available USB Port
* 2 GB RAM (or higher recommended)
* 2 GB free HDD space (or larger recommended)

Spesifikasi Berat Produk

* Berat Bersih 3,78 Kg
* Berat Kotor 9 Kg
* Dimensi Produk (P) 41,8 x (L) 32,6 x (T) 10,1 cm
* Dimensi Kardus Luar (P) 59 x (L) 56 x (T) 28 cm

**Note :

Untuk Pengiriman di Luar Daerah, kami menyarankan untuk menggunakan Packing Kayu
Tambahan untuk Meminimalisir Kerusakan dalam Pengiriman Jarak Jauh.

Harga Belum Termasuk Biaya Pengiriman. Mohon tanyakan kepada kami terlebih
dahulu / silahkan Pilih kurir yang anda butuhkan.

==========================================================
