HDMI Matrix Switcher & Splitter 4x2 4K EDID audio Gaintech

Detail HDMI Matrix Switcher & Splitter 4x2 4K EDID audio Gaintech

Matrix HDMI 4x2 dapat menghubungkan 4 sumber sinyal HDMI ke 2 HDMI terminal tampilan dengan Audio serat optik atau keluaran headphone stereo aux 3.5mm . HDMI Matrix memungkinkan 4 perangkat HDMI untuk switch atau split dengan mudah dua monitor atau proyektor yang kompatibel dengan HDMI. Dan setiap port keluaran dapat mewujudkan output audio independen dengan serat optik atau kepala stereo telepon. Perangkat kami menawarkan solusi untuk kebisingan, ruang, dan keamanan kekhawatiran, kontrol pusat data, distribusi informasi, konferensi ruang presentasi, sekolah dan lingkungan pelatihan perusahaan

Features:

*Support HDMI 2.0b HDCP 2.2

* Support 3D video format

*Support highest resolution up to 3840*2160/60 HZ

*Support 18.5Gbps x 3 data rate and tmds clock up to 600Mhz

* Support deep color 8/10/12/24 bit

*Support HDMI audio outputs, 3.5 mm earphone jack and optical output at same time

* 4 HDMI inputs switch and split to 2 HDMI displays

* Support LPCM/Dolby/DTS 5.1 audio


Wide Compatibility

Support HDCP 2.2, compatible with HDMI 2.0b. Input support: Computer, PS3, PS4 pro, Xbox, Xbox one, Nintendo Switch, HD player, Fire TV, Apple TV etc. Output support: Projector, HDTV etc.

Settable EDID

EDID switch sets the video and audio mode of the HDMI source. Flexible EDID switching provides 16 switching modes that can be met for different resolution needs.


Specifications:

HDMI Version : 2.0b
HDMI Resolution : up to 3840x2160/60Hz
Support Video format : 8 / 10 / 12 / 24 / 32 / 48bit deep color
Support Audio format : LPCM / DTS / Dolby-AC3
Max Bandwidth : 600MHz
MAX band Rate : 18.5Gbps x 3
Input cable Distance : <10M AWG26 HDMI 2.0b Standard cable
Output cable Distance : <15M AWG26 HDMI 2.0b standard cable
HDMI Input : 4
HDMI Output : 2
Max working currrent : 600mA
Power adapter : 5V
Dimension : 170x56x24
Weight : 0.175Kg

Package contents

1x HDMI Matrix 4x2

1x 5V power adapter

1x IR Remote Control

1x User Manual
