PSU Silverstone 500W 80+ ST50F-ES230 - Power Supply

Detail PSU Silverstone 500W 80+ ST50F-ES230 - Power Supply

PSU Silverstone 500W 80+ ST50F-ES230 - Power Supply
Garansi Resmi 5 Tahun

ST50F-ES230

80 PLUS 230V EU 500W ATX power supply
High efficiency with 80 PLUS certification
24/7 continuous power output with 40℃ operating temperature
Class-leading single +12V rail
Active PFC Circuitry
PCI-E 8pin and PCI-E 6pin connector support
Silent running 120mm fan with 18dBA

Product Specifications
Product No.SST-ST50F-ES230
Max. DC Output 500W
Power density 277W per liter
Load Range
Output +3.3V +5V +12V +5VSB -12V
Max.(Amps) 18A 17A 38A 2.5A 0.3A
Peak (Amps) / / / / /
Min.(Amps) 0A 0A 0A 0A 0A
Range (%) ±5% ±5% ±5% ±5% ±10%
Line Reg.(%) ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV
Combined +3.3V & +5V 110W
Combined +12V 456W
Input Voltage 180 ~ 264Vrms
Input Frequency Range 47Hz ~ 63Hz
PFC Active PFC.（PF>0.9 at Full Load）
Efficiency 82%~85% @ 20% ~ 100% loading
MTBF 100,000 hours
Operating temperature 0°C ~ 40°C
Protection Over power protection
Over voltage protection Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector（500mm）
1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）
2 x 8 / 6-Pin PCIE connector（"500mm / 150mm"）
2 x SATA connector and
1 x 4-Pin Peripheral connector and
1 x 4-Pin Floppy connector （500mm / 150mm / 150mm / 150mm）
2 x SATA connector and
2 x 4-Pin Peripheral connector（500mm / 150mm / 150mm / 150mm）
Cooling System Silent 120mm fan
Noise Level 18 dBA minimum
Certification 80 PLUS
Dimension 150 mm (W) x 86 mm (H) x 140 mm (D)
Weight 1.31kg
Other GPU Support list
Compatible with ATX12V v2.4
