Noctua NH-L12s CPU Cooler

Detail Noctua NH-L12s CPU Cooler

* General

Notes and warnings The NH-L12S is a low-profile quiet cooler designed for use in Small Form Factor cases and HTPC environments. While it provides first-rate performance in its class, it is not suitable for overclocking and should be used with care on CPUs with more than 95W TDP (Thermal Design Power). Please consult our CPU compatibility list and TDP guidelines to find out whether the NH-L12S is recommended for your CPU.
Cooler Specification
Socket compatibility Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1156, LGA1155, LGA1151, LGA1150 & AMD AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+ (backplate required)
Height (without fan) 70 mm
Width (without fan) 128 mm
Depth (without fan) 146 mm
Weight (without fan) 390 g
Height (with fan) 70 mm
Width (with fan) 128 mm
Depth (with fan) 146 mm
Weight (with fan) 520 g
Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Max. TDP see CPU compatibility list
Fan compatibility 120x120x15 & 120x120x25
Scope of delivery
1x NF-A12x15 PWM premium fan
Low-Noise Adaptor (L.N.A.)
NT-H1 high-grade thermal compound
SecuFirm2 mounting kit
Noctua metal case-badge


* FAN Specification

Model 1x Noctua NF-A12x15 PWM
Bearing SSO2
Max. rotational speed (+/- 10%) 1850 RPM
Max. rotational speed with L.N.A. (+/- 10%) 1400 RPM
Min. rotational speed (PWM, +/-20%) 450 RPM
Max. airflow 94,2 m³/h
Max. airflow with L.N.A. 70,8 m³/h
Max. acoustical noise 23,9 dB(A)
Max. acoustical noise with L.N.A. 16,8 dB(A)
Input power 1,56 W
Voltage range 12 V
MTTF > 150.000 h

Gambar produk
