Noctua CPU Cooler NH-U14S TR4-SP3 for AMD TR4

Detail Noctua CPU Cooler NH-U14S TR4-SP3 for AMD TR4

NOCTUA CPU Cooler NH-U14S TR4-SP3 Premium Grade 120mm For AMD TR4 AMD THREADRIPPER COOLER_x000D_
_x000D_
_x000D_
General_x000D_
Notes and warnings Please note that the NH-U14S TR4-SP3 is a dedicated version for the AMD TR4/SP3 socket. Due to its customised larger base, it cannot be used on any other sockets and is incompatible with Noctua’s standard mounting kits._x000D_
_x000D_
Cooler Specification_x000D_
Socket compatibility AMD TR4 & SP3_x000D_
Height (without fan) 165 mm_x000D_
Width (without fan) 150 mm_x000D_
Depth (without fan) 52 mm_x000D_
Height (with fan) 165 mm_x000D_
Width (with fan) 150 mm_x000D_
Depth (with fan) 78 mm_x000D_
Weight (without fan) 865 g_x000D_
Weight (with fan/s) 1030 g_x000D_
Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating_x000D_
Max. TDP see TDP guide_x000D_
Fan compatibility 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25_x000D_
Scope of Delivery_x000D_
NF-A15 PWM premium fan_x000D_
Low-Noise Adaptor (L.N.A.)_x000D_
NT-H1 high-grade thermal compound_x000D_
SecuFirm2 mounting kit_x000D_
Anti-vibration pads and fan-clips for second NF-A15 (optional)_x000D_
Noctua metal case-badge_x000D_
Warranty 6 Years_x000D_
FAN Specification_x000D_
Model Noctua NF-A15 PWM_x000D_
Bearing SSO2_x000D_
Max. Rotational Speed (+/- 10%) 1500 RPM_x000D_
Max. Rotational Speed with L.N.A. (+/- 10%) 1200 RPM_x000D_
Min. Rotational Speed (PWM, +/-20%) 300 RPM_x000D_
Max. Airflow 140,2 m³/h_x000D_
Max. Airflow with L.N.A. 115,5 m³/h_x000D_
Max. Acoustical Noise 24,6 dB(A)_x000D_
Max. Acoustical Noise with L.N.A. 19,2 dB(A)_x000D_
Input Power 1,56 W_x000D_
Voltage Range 12 V_x000D_
MTTF > 150.000 h_x000D_
_x000D_
WEB : http://noctua.at/en/nh-u14s-tr4-sp3/specification
