Noctua NH-U9S CH, BK CPU Cooler

Detail Noctua NH-U9S CH, BK CPU Cooler

Spesifikasinya gan :
Cooler Specification

Socket compatibility
Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1200 LGA1156, LGA1155, LGA1151, LGA1150 & AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required), AM4

Height (without fan)
125 mm

Width (without fan)
95 mm

Depth (without fan)
68 mm

Height (with fan)
125 mm

Width (with fan)
95 mm

Depth (with fan)
95 mm

Weight (with fan)
618 g

Material
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

Max. TDP
see CPU compatibility list

Fan compatibility
92x92x25

Scope of delivery
Black NH-U9S heatsink

NF-A9 PWM chromax.black premium fan

NA-RC7 Low-Noise Adaptor (L.N.A)

NT-H1 high-grade thermal compound

Black SecuFirm2 mounting kit

Black fan-clips for second NF-A9

Noctua Metal Case-Badge

Warranty
6 Years

FAN Specification

Model
Noctua NF-A9 PWM chromax.black

Bearing
SSO2

Max. rotational speed (+/- 10%)
2000 RPM

Max. rotational speed with L.N.A. (+/- 10%)
1550 RPM

Min. rotational speed (PWM, +/-20%)
400 RPM

Max. airflow
78,9 m³/h

Max. airflow with L.N.A.
62,6 m³/h

Max. acoustical noise
22,8 dB(A)

Max. acoustical noise with L.N.A.
16,3 dB(A)

Input power
1,2 W

Voltage range
12 V

MTTF
> 150.000 h
