Detail Motherboard Biostar Racing X470GT8 Socket AM4
Motherboard Biostar Racing X470GT8
Support AMD Ryzen CPU / APU AMD X470 single chip architecture Support 4-DIMM DDR4-3200(OC)/2933(OC)/2667/2400/2133/1866 Up to 64GB maximum capacity Support USB 3.1 Gen2 Type C Support M.2(32Gb/s) Chipset AMD X470 CPU SUPPORT AMD A-series APU / Ryzen CPU / NPU for Socket AM4 Maximum CPU TDP (Thermal Design Power) : 105Watt MEMORY Support Dual Channel DDR4 1866/ 2133/ 2400/ 2667/ 2933(OC)/ 3200(OC) MHz 4 x DDR4 DIMM Memory Slot Max. Supports up to 64GB Memory * DDR4 2667 for AMD Ryzen CPU Athlon 200GE does not support ECC DDR4 memory module. INTEGRATED VIDEO STORAGE 6 x SATA3 Connectors (6GB/s) Support SATA RAID: 0,1,10 Support Hot-Plug in AHCI mode 1 x M.2 Key M 32Gb/s Connector(32Gb/s) Support both PCIE NAND for PCIE SSD and SATA NAND for SATA SSD LAN Intel I211AT GbE LAN - Gigabit Ethernet PHY CODEC Realtek ALC1220 8-Channel Blu-ray Audio Support Blu-ray Audio Support SPDIF_out Support Biostar Hi-Fi USB 1 x USB 3.1 Gen2 Type-C Port 1 x USB 3.1 Gen2 Type-A Port 4 x USB 3.1 Gen1 Ports 2 x USB 3.1 Gen1 Header 2 x USB 2.0 Header DIMENSION ATX Form Factor Dimension: 30.5 cm x 24.4 cm ( W x L ) OS SUPPORT Support Windows 10(x64) Support Windows 7 (x64) for Bristol / Summit /Pinnacle Ridge only BUNDLE SOFTWARE Racing GT Utility BullGuard
