BIOSTAR Motherboard B660MX-E Intel B660 LGA1700 DDR4

Detail BIOSTAR Motherboard B660MX-E Intel B660 LGA1700 DDR4

Terima kasih Sudah berkunjung di Kurnia Abadi Semesta.
Demi kenyamanan bersama terkait harga, stock, warna, dll, harap konfirmasi terlebih dahulu sebelum order.
Terima kasih

B660MX-E Ver. 6.0
Socket : 1700
Supports 12th Generation Intel Core™ Processor
Intel B660 single chip architecture
Supports 2-DIMM DDR4- 1866/ 2133/ 2400/ 2666/ 2800/ 2933/ 3200/ 3600(OC)/ 3800(OC)/ 4000(OC) up to 64 GB Memory
Supports PCIe 4.0
Supports PCIe M.2 3.0 (32Gb/s)
Supports HDMI 4K2K
Supports USB 3.2 Gen1
Support WiFi 6 & 6E module (No WiFi card included)

Chipset Intel B660
MEMORY Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2800/ 2933/ 3200/ 3600(OC)/ 3800(OC)/ 4000(OC)
STORAGE -- Total supports 1x M.2 socket and 4x SATA III (6Gb/s) ports
4 x SATA III Connector (6Gb/s) : Supports AHCI
1 x M.2 (M Key) Socket (M2_PCIEG3_32G-SATA):
Supports M.2 Type 2240 /2260 /2280 SSD module
Supports PCI-E 3.0 x4 (32Gb/s) & SATA SSD
AUDIO CODEC ALC897
EXPANSION SLOT 1 x PCIe 3.0 x1 Slot
1 x PCIe 4.0 x16 Slot
INTERNAL I/O 4 x SATA III Connector (6Gb/s)
1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel CNVi
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Internal Stereo Speaker Header
1 x Clear CMOS Header
DIMENSION Micro ATX Form Factor Dimension: 23.6cm x 20.8cm ( W x L )
BUNDLE SOFTWARE BullGuarD
ACCESSORIES 2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x Quick Guide
1 x WiFi antenna accessories
