Montech CENTURY MINI 750 750Watt 80 Plus Gold Full Modular Power Supply

Detail Montech CENTURY MINI 750 750Watt 80 Plus Gold Full Modular Power Supply

CENTURY MINI 750 GOLD
Small Size, Big Power

​SFX Form Factor
Full Modular Cabling
80 PLUS Gold Certified
100% Japanese High Quality Capacitors
Compatible With Any Case
Seven Year Warranty

SPECIFICATION:

Product Name


CENTURY MINI 750

Type


Intel SFX12V

Input Voltage


100-240Vac

Input Current


12A

Input Frequency


47-63Hz

Dimensions (L*B*H)


100*125*63.5mm

Fan Size


90mm

MTBF


>100,000 Hours

Operating Temperature


0-45°C

Protections


OPP/ SCP / OTP/ OVP / UVP/OCP

Regulatory


cTUVus / TUV / CB / CE / CCC / RoHS / FCC / UKCA

Connectors


M/B 20+4Pin


1

CPU 4+4Pin


2

PCIE 6+2


4

SATA


6

Molex 4Pin


3

FDD


1

AC INPUT


100-240Vac 47-63Hz 12.0A

DC OUTPUT


+3.3V


+5V


+12V


-12V


+5VSB

Max. Output Current


20A


20A


62.5A


0.3A


2.5A

Max. Output Power


120W


750W


3.6W


12.5W

Total POWER


750W
