Detail Montech CENTURY 850 850Watt 80 Plus Gold Full Modular Power Supply
CENTURY 850 Gold Fully Modular Gold Certified Power Supply
80 plus Gold certified, with 91% efficiency or higher under typical loads Fully modular to reduce clutter and improve airflow 100% high quality Japanese 105°C/221°F capacitors, full- bridge LLC resonant converter and DC-DC technology Fluid Dynamic Bearing premium fan enhanced quiet operation and increased lifespan Heavy-duty protections, including OCP, OVP, UVP, OPP, SCP, and OTP 5 year limited Warranty and exceptional Montech Customer Support
SPECIFICATION:
Product Name
CENTURY 850
ATX Version
ATX12V
PFC
Active PFC (>0.9 typical)
Input Voltage
100-240Vac
Input Current
12A
Input Frequency
47-63Hz
Dimensions (L*B*H)
140*150*86mm
Fan Size
120mm ( FDB Fan )
Hold Up Time
10msec (minimum) at 80% of full load at 230Vac input.
Efficiency
90% Typically
MTBF
>100,000 Hours
Operating Temperature
0-45°C
Protections
OCP/OVP/UVP/OPP/SCP/OTP
Regulatory
cTUVus / TUV / CB / CE / RoHS / FCC
Connectors
M/B 20+4Pin
1
CPU 4+4Pin
2
PCIE 6+2
6
SATA
10
Molex 4Pin
3
FDD
1
AC Input
100-240Vac 47-63Hz 12.0A
DC Output
+3.3V
+5V
12V
-12V
+5VSB
Max. Output Current
20A
20A
70.5A
0.3A
2.5A
Max. Output Power
110W
846W
3.6W
12.5W
Total POWER
850W
