Montech CENTURY 650 Gold Fully Modular I 650W 80+ Gold Power Supply

Detail Montech CENTURY 650 Gold Fully Modular I 650W 80+ Gold Power Supply

#GARANSI RESMI 5 TAHUN

MONTECH CENTURY GOLD 650W
80 plus Gold certified, with 91% efficiency or higher under typical loads
Fully modular to reduce clutter and improve airflow
100% high quality Japanese 105°C/221°F capacitors, full-
bridge LLC resonant converter and DC-DC technology
Fluid Dynamic Bearing premium fan enhanced quiet operation and increased lifespan
Heavy-duty protections, including OCP, OVP, UVP, OPP, SCP, and OTP
5 year limited Warranty.

SPECIFICATIONS
Product Name
CENTURY 650

ATX Version
ATX12V

PFC
Active PFC (>0.9 typical)

Input Voltage
100-240Vac

Input Current
9A

Input Frequency
47-63Hz

Dimensions (LxBxH)
140x150x86mm

Fan Size
120mm ( FDB Fan )

Hold Up Time
10msec (minimum) at 80% of full load at 230Vac input.

Efficiency
90% Typically

MTBF
>100,000 Hours

Operating Temperature
0-45°C

Protections
OCP/OVP/UVP/OPP/SCP/OTP

Regulatory
cTUVus / TUV / CB / CE / RoHS / FCC

Connectors
M/B 20+4Pin
1

CPU 4+4Pin
2

PCIE 6+2
4

SATA
8

Molex 4Pin
3

FDD
1

AC Input
100-240Vac 47-63Hz 9.0A

DC Output
+3.3V

+5V

12V

-12V

+5VSB

Max. Output Current
20A

20A

54A

0.3A

2.5A

Max. Output Power
100W

648W

3.6W

12.5W

Total POWER
650W
