Detail LCD Module Display Monitor Nokia 5110

hai kak. Mohon maaf untuk minimal order 20 ribu ya kak baru bisa kita proses, diluar ongkirSTOCK = 20 pcs

Introduction:

Nokia5110 LCD mobile phone is the second hand disassemble screen, the site for the sale of liquid crystal are selected fineness and quality are very good.

The bottom plate for the site design, four holes have positioning holes, while providing two rows of upper and lower wiring ports, arranged as follows:

RST - Reset
CE - Chip Select
DC - data / command selection
DIN - serial data cable
CLK - serial clock line
VCC - power input (3.3v and 5v can be, after experimental verification, no problem)
BL - Backlight control terminal
GND - ground wire
Interface for the serial SPI interface, this site provides 51 single-chip, Nios II soft-core driver routines!

Gambar produk

LCD Module Display Monitor Nokia 5110
LCD Module Display Monitor Nokia 5110
