CAMERA Image Sensor: 2MP CMOS Signal System: PAL/NTSC Effective Pixel: 1920 (H) x 1080 (V) Min. Illumination: 0.02 Lux@(F1.2, AGC ON), 0 Lux with IR Shutter Time: 1/25 (1/30)s to 1/50,000s Lens: 2.8mm, 3.6mm Field of View: - 2.8mm, horizontal FOV: 96.5", vertical FOV: 48.9", diagonal FOV: 120.5" - 3.6mm, horizontal FOV: 76.9", vertical FOV: 40.6", diagonal FOV: 92.0" Lens Mount: M12 Day & Night: IR cut filter Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° Synhronization: Internal synchronization Video Frame Rate: 1080p@25fps/1080p@30fps Video Frame Rate: PAL: 1080p@25fps, NTSC: 1080p@30fps
MENU Image Mode: STD/HIGH-SAT AGC: High/Medium/Low/Off D/N Mode: Auto/Color/BW (Black and White) BLC: Support DW DR: Support Language: English Functions: Brightness, Sharpness, DNR, Mirror, Smart IR
INTERFACE Video Output: 1 HD analog output Switch Button: TVI/AHD/CVI/CVBS
GENERAL Operating Conditions:P -40°C to 60°C (-40°F to 140°F, Humidity: 90% or less (non-condensation) Power: 12VDC ±15%, Max. 2.1W Protection Level: IP66 Material: Plastic IR Range: Up to 20m Dimensions: Ø85.4mm x 76.12mm (Ø3.38" x 2.67")
