CAMERA Image Sensor: 2MP CMOS Signal System: PAL/NTSC Resolution: : 1920 (H) x 1080 (V) Frame Rate: - TVI: 1080p@30fps, 1080p@25fps - AHD: 1080p@30fps, 1080p@25fps - CVI: 1080p@30fps, 1080p@25fps - CVBS: PAL/NTSC Min. Illumination: 0.01 Lux@(F1.6, AGC ON), 0 Lux with IR Shutter Time: PAL: 1/25 s to 1/50,000 s, NTCS: 1/30 s to 1/50,000 s Lens: 2.8mm, 3.6mm, 6mm fixed lens Field of View: - 2.8mm, horizontal FOV: 106.4°, vertical FOV: 57.9°, diagonal FOV: 124.6° - 3.6mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° - 6mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8° Lens Mount: M12 Day & Night: ICR WDR (Wide Dynamic Range): Digital WDR Audio: Built-in mic Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
MENU Image Mode: STD/HIGH-SAT AGC: Yes Day/Night Mode: Auto/Color/BW (Black and White) White Balance: Auto/Manual AE (Auto Exposure) Mode: DWDR/BLC/HLC/Global Noise Reduction: 2D DNR Language: English Functions: Brightness, Sharpness, Mirror, Smart IR, Saturation
INTERFACE Video Output: Switchable TVI/AHD/CVI/CVBS
GENERAL Operating Conditions:P -40°C to 60°C (-40°F to 140°F, Humidity: 90% or less (non-condensing) Power Supply: 12 VDC ±25% Power Consumption: Max. 2.7 W Protection Level: IP66 Material: Plastic IR Range: Up to 20m Communication: HIKVISION-C Dimensions: Ø 84.6mm x 78.9mm (Ø 33" x 3.11") Weight: Approx. 140.5g (O.31 lb.)
