JUAL HT VOXTER V838 MURAH

Detail JUAL HT VOXTER V838 MURAH

SPESIFIKASI : VOXTER V838 VHF

Features

VHF 5 W Output Power
128 Groups of Memory Channels
25 KHz / 12.5 KHz Channel Spacing Compatible
Automatic Numbering Identification ( ANI ) Code
Built-in Voice Operate Transmit ( VOX )
All Channels Scan and Priority Channel Scan
Scrambler
Three Color LCD Backlight Adjustable
Emergency Alarm
Programmable by PC with Software
50 CTCSS and 104 DCS Normal / Inverted Selectable
Time - Out Timer ( TOT )
Busy Channel Lockout
2 Tone / 5 Tone Code ( Optional )
FM Radio Broadcasting Receiver

General
Frequency Range
VHF : 136 - 174 Mhz

Working Temperature -20C ~ +50C
Operating Voltage DV 7.2V
Operate Mode Simplex or Semi Duplex

Dimension : 100 x 55 x 32mm ( not include antenna )
Weight : 220g ( including battery )
Antenna Impedance50

Transmitter
Frequency Stablility 2.5 ppm
Output Power 5 W
Max Frequency Deviation 5 KHz
Audio Distortion 3%
Modulation Character +3 dB ~ -3 dB
Adjacent Channel Power 65d B
Spurious Radiation 7.5 W
Occupied Bandwidth 16 KHz

Receiver
RF Sensitivity < 0.2
Audio Distortion 3%
Audio Response +2 dB ~ -10 dB
Adjacent Channel Sellectivity 60 dB
Intermodulation Rejection 60 dB
Spurious Response 60 dB
Blocking 60 dB

Garansi 1 Tahun Service

Gambar produk
