HSAIRPO CM3F2E-PoE Media Converter 3FO 2ETH 10/100Mbps PoE HS AIRPO

Detail HSAIRPO CM3F2E-PoE Media Converter 3FO 2ETH 10/100Mbps PoE HS AIRPO

HSAIRPO CM3F2E-PoE
Media Converter 3FO 2ETH 10/100Mbps PoE
The CM3F2E-PoE is a 10/100Mbps adaptive fiber switch. It has 2 10/100Mbps Ethernet ports and 3 155Mbps fiber ports. There are also many other advantages such as isolation protection, good data security, working stability and easy maintenance.
Key Features :
- 3 Fiber (AAB) 2 Ethernet
- Support the switch between 100Base-FX and 100Base-TX
- 3*155Mbps full duplex fiber ports, 2*10/100Mbps adaptive Ethernet ports
- Support 10/100Mbps rate, support MDI/MDI-X adaptive, support full/half duplex adaptive
- Each port has the complete LED Indicator light for installation, commissioning and maintenance
- Support single mode single fiber,single mode dual fiber, multi-mode dual fiber and SFP slot
- Support IEEE802.1d Spanning tree
- Support IEEE802.1p traffic prioritization protocol
- Support high performance Qos function on each port
- Support broadcast storm protection
- Support max forwarding packet length 2048 bytes option
- Support IEEE 802.3x flow control and back pressure control
- Require no configuration and will instantly operate as soon as you power it up
- Adopt low power consumption Realtek chip, only 2.5W in full load condition
- Support non-standard POE function
- Built-in IC protection from electrostatic discharge during thunder stroke
Ethernet Port
- Connector: RJ45
- Data Rate: 10/100Mbps
- UTP Type: UTP-5E or higher level
Fiber Port
- Connector: SC/FC/ST slot
- Data Rate: 155Mbps
- Optical wavelength: 850nm/1310nm/1490nm/1550nm
- Fiber(Single mode): 8/125,8.7/125,9/125,10/125
Performance
- Processing Type: direct forwarding
- MAC Table Size: 2K
- Buffer Space: 2048 bit
- Back bandwidth: 1G
- Maximum Packet Length: 2048 bytes
- Time Delay:<150μs
- TX Power: -14~-8dBm
- Sensitivity: -32dBm
- Link Budget: 18dBm
Power
- Input Voltage: AC100V~240V 50/60Hz
- Connector: DC Socket
- Power Supply: 12v
- Power Consumption: 1.8W~2.5W
Environment
- Storage Temperature: -40~70?
