HIOSO EPON OLT HA7302CST 2port SFP

Detail HIOSO EPON OLT HA7302CST 2port SFP

Feature :
- Supply 2 SFP PON ports, 2 GE uplink ports, 1 10/100M RJ45 management port
- Support SNMP management and WEB management
- Each PON port support maximum 1:64 split ratio, total 128 ONUs access
- Distance can reach 20km under 1:32 split ratio, in 10km maximum 1:64
- Support to work with different brands ONUs to establish passive network
- 1U rack design, inside fan,better for heat dissipating and reliability operating
- Apply for town,village fiber network and surveillance, apply for FTTX network, to transmit IP phone, data,IPTV and other IP services access


Parameter Specifications
Operating
wavelength
1310（RX）/1490（TX）
Optical power +0 ~ +3dBm
Receiving sensitivity -27dBm
Max distance 20km
Max splitter ratio 1:64
Capacity 2 PON, standard: 64 ONUs maximum:128 ONUs
MAC 8K
Uplink port 2 10/100/1000 Ethernet RJ45 ports / 2 Gigabit SFP ports optional
PON port 2 SC fiber ports
Control port RJ45 console port, to debug the device
MTBF 100,000 hours
EPON traits
Support IEEE802.3ah
Support DBA with minimum1Kbps granularity adjustable
Support 1Gbps up link and down link symmetrical bandwidth
Support AES-128 encryption to each Logical Link Identifier
Support powerful OAM function, implement telnet management, maintenance and upgrade
Support auto discovery and auto register of ONU (real-time
operation)
Protocols supported
Support IEEE802.3, IEEE802.3u, IEEE802.3ab
Support IEEE802.1Q VLAN
Support IEEE 802.1P QoS
Management CLI and GUI, SNMP, WEB
Support DHCP Snooping
Support Ipv4 address learning based at DHCP Snooping
Support ARP Snooping, QoS etc

Gambar produk
