Detail HIOSO EPON OLT HA7302CS AC DC 2-PON Termasuk SFP PX20+++

HIOSO EPON OLT HA7302CS AC DC 2-PON Termasuk SFP PX20+++

Operating :
~ wavelength 1310(RX)/1490(TX)
~ Optical power +0 ~ +7dBm
~ Receiving sensitivity -27dBm
~ Max distance 20km
~ Max splitter ratio 1:64
~ Capacity 2 PON, standard: 64 ONUs maximum:128 ONUs
~ MAC 8K
~ Uplink port 2 10/100/1000 Ethernet RJ45 ports / 2 Gigabit SFP ports optional
~ PON port 2 SC fiber ports
~ Control port RJ45 console port, to debug the device
~ MTBF 100,000 hours
~ EPON traits
~ Support IEEE802.3ah
~ Support DBA with minimum1Kbps granularity adjustable
~ Support 1Gbps up link and down link symmetrical bandwidth
~ Support AES-128 encryption to each Logical Link Identifier
~ Support powerful OAM function, implement telnet management, maintenance and upgrade
~ Support auto discovery and auto register of ONU (real-time operation)

Protocols supported :
~ Support IEEE802.3, IEEE802.3u, IEEE802.3ab
~ Support IEEE802.1Q VLAN
~ Support IEEE 802.1P QoS
~ Management CLI and GUI, SNMP, WEB
~ Support DHCP Snooping
~ Support Ipv4 address learning based at DHCP Snooping
~ Support ARP Snooping, QoS etc
