Fan Casing Noctua NF-A4X10 FLX

Detail Fan Casing Noctua NF-A4X10 FLX

Featuring advanced aerodynamic design measures such as Flow Acceleration Channels and Noctua’s AAO frame, the NF-A4x10 FLX is a highly optimised, premium quality quiet fan in 40x10mm size. Smooth Commutation Drive technology and Noctua’s reference class SSO2 bearings guarantee superb running smoothness and excellent long-term stability. Topped off with modular cabling, a Low-Noise Adaptor and OmniJoin Adaptor Set as well as 6 years manufacturer’s warranty, the NF-A4x10 is a premium choice for the highest demands.


FAN Specification :

Size 40x40x10 mm
Mounting hole spacing 32x32 mm
Connector & pin-configuration 3-pin
Cable length 20cm + 30cm NA-EC1 extension cable
Bearing SSO2
Blade geometry A-Series with Flow Acceleration Channels
Frame technology AAO (Advanced Acoustic Optimisation)
Rotational speed (+/- 10%) 4500 RPM
Rotational speed with L.N.A. (+/- 10%) 3700 RPM
Airflow 8,2 m³/h
Airflow with L.N.A. 6,6 m³/h
Acoustical noise 17,9 dB(A)
Acoustical noise with L.N.A. 12,9 dB(A)
Static pressure 1,78 mm H₂O
Static pressure with L.N.A. 1,21 mm H₂O
Max. input power 0,6 W
Max. input current 0,05 A
Operating voltage 12 V
MTTF > 150.000 h
Scope of delivery
Low-Noise Adaptor (L.N.A.)
3:2 Pin Adaptor
OmniJoin Adaptor Set
30cm Extension Cable
4 Vibration-Compensators
4 Fan Screws
Warranty 6 years
