Detail CATV AMPLIFIER boster 220V 2-OUTPUT
CATV AMPLIFIER BOSTER 220V• BARU
• OUTDOOR INDOOR
(1) EQ RANGE: 0~-20DB ADJUST CONTINUOUSLY
(3) GAIN RANGE: 0-~20DB ADJUST CONTINUOUSLY
(4) OUTPUT MODE: 2 SPLITTER.
(5) POWER SUPPLY: 220V/AC
(6) OVER-CURRENT PROTECTION AND LIGHTNING-PROOF.
RF PARAMETER:
FREGUENCY RANGE 45~550/750 / 860MHZ
EQ ADJUSTMENT 0~20DB ADJUSTABLE
FLATNESS IN BAND ≤± 0.75DB
IN/OUT IMPEDANCE 75 W
RETURN LOSS ≥ 16:87~550MHZ ≥ 14:550~862MHZ
OUTPUT LEVEL ≥110DBUV ≥118DBUV
NOMINAL WORKING GAIN 32DB 40DB SIGNAL
POWER SUPPLY 220V/AC
C/CTB 61DB 61DB
CURRENT 220V/AC
NOISE FIGURE
RF CONNECTOR TYPE F- CONNECTOR
ATT ADJUSTMENT 0~20DB ADJUSTABLE
__________________________________
