Cambium XV2-2T Outdoor Wi-Fi 6 Access Points|WiFi 6 Outdoor XVT2 2T

Detail Cambium XV2-2T Outdoor Wi-Fi 6 Access Points|WiFi 6 Outdoor XVT2 2T

Cambium XV2-2T Outdoor Wi-Fi 6 Access Points|WiFi 6 Outdoor
802.11ax Dual-radio, 2x2, HE 120º Sector Antenna

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Access Point Specifications
Note: Some features will be included on subsequent firmware releases.
FCC Ch 1–11, 36–48, 52–64, 100–144, 149–165
ISED Ch 1–11, 36–48, 52–64, 100–144, 149–165
ETSI Ch 1–13, 36–48, 52–64, 100–144
ROW (Individual country limits may apply)
Ch 1–14, 36–48, 52–64, 100–144, 149–177
2400–2483.5 MHz, 5150–5895 MHz
Radios 5 GHz 802.11 a/n/ac Wave 2/ax, 2x2
2.4 GHz 802.11 b/g/n/ax, 2x2
BLE 4.1
Wi-Fi 802.11 a/b/g/n/ac Wave 2/ax
SSID
Security
WPA3, WPA2 (CCMP, AES, 802.11i), WPA2
Enterprise (802.1x/EAP), WPA PSK (TKIP),
WEP, Open
Max PHY
Rate
5 GHz radio 1,201 Mbps
2.4 GHz radio 573.5Mbps
Ports 1 x IEEE 100/1000/2500 Mbps
1 x IEEE 10/100/1000 Mbps Ethernet with SW
configurable passive PoE output of 30V or 48V up
to 30 Watts
Antenna 5 GHz 13.5 dBi, Sector
2.4 GHz 11 dBi, Sector
Max EIRP 5 GHz 36 dBm
2.4 GHz 35 dBm
EIRP may be limited by country regulations
LTE Filter
Band 38, 40
Power 20W max
Up to 50W when powering an auxiliary device
Dimensions 582 mm x 200 mm x 80 mm
(22.91 in x 7.87 in x 3.15 in)
Weight 1,200 g (2.64 lbs)
Security Kensington lock slot
LEDs Multi-color status LEDs
Ambient
Operation Temperature
-40ºC to 65ºC
(-40ºF to 149ºF)
Storage Temperature
-40ºC to 70ºC
(-40ºF to 158ºF)
Humidity 95% RH non-condensing
MTBF 25ºC = 674,966 hours
65ºC = 197,106 hours
Mount Options Pole or wall mounting.
Pole diameter: MIN 30 mm / MAX 75 mm
Certifications
(Compliance)
Wi-Fi Alliance 802.11 a/b/g/n/ac/ax, FCC, IC,
CE, EN 60601-1-2, EN 60950-1,IEC 62368-1
Safety, EN 60601-1-2 Medical, EN 61000-4-
2/3/5 Immunity, EN 50121-1 Railway EMC, EN
50121-4 Railway Immunity, IEC 61373 Railway
Shock & Vibration, EN 62311 Human Safety/RF
Exposure, WEEE & RoHS
