Cambium EPMP Force 200L | Cambium ePMP F200L ( Setara PBE M5 400 )

Detail Cambium EPMP Force 200L | Cambium ePMP F200L ( Setara PBE M5 400 )

ePMP Force 200L
Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments.

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

SPECTRUM
Channel SpacingConfigurable on 5 MHz increments
Frequency RangeWide Band Operation 4910–5970 MHz
Channel Width MHz5 | 10 | 20 | 40

PERFORMANCE
ARQYes
Nominal Receive Sensitivity (w/FEC) @200MHz ChannelMCS0 -88 dBm; MCS7 = -70 dBm
Nominal Receive Sensitivity (w/FEC) @40MHz ChannelMCS0 = -86 dBm; MCS7 = -68 dBm
Modulation Levels (Adaptive)MCS0 (BPSK) to MCS7 (64QAM 5/6)
Quality of ServiceThree level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority
Transmit Power Range+3 to 28 dBm (combined, to regional EIRP limit) (1 dB interval)

PHYSICAL
Surge Suppression1 Joule Integrated
EnvironmentalIP55
Temperature-30°C to 55°C (-22°F to 122°F)
Weight1.6 kg (3.5 lbs)
Wind Survival200 km/h (124 mph)
Pole Diameter Range2.5 - 7.5 cm (1.0 to 3.0 in)
Power Consumption8 W Maximum, 5 W Typical
Input Voltage30 V Passive PoE (14-30 V DC input)

Gambar produk
