BIOSTAR Motherboard TB360-BTC PRO Intel B360 LGA 1151 DDR4 ATX

Detail BIOSTAR Motherboard TB360-BTC PRO Intel B360 LGA 1151 DDR4 ATX

Terima kasih Sudah berkunjung di Kurnia Abadi Semesta.
Demi kenyamanan bersama terkait harga, stock, warna, dll, harap konfirmasi terlebih dahulu sebelum order.
Terima kasih

TB360-BTC PRO Ver. 6.x
Socket : 1151

Supports 9th & 8th Generation Intel® Core™ Processor
Intel B360 single chip architecture
Support 2-DIMM DDR4-1866/2133/2400/2666 up to 32G maximum capacity
Support 12 x PCI-E 3.0 slots
Support M.2 (6Gb/s) Connector
Support HDMI Connector

Chipset
Intel B360

CPU SUPPORT
9th Gen Intel® Core™ i9 LGA 1151 Processor
9th Gen Intel® Core™ i7 LGA 1151 Processor
9th Gen Intel® Core™ i5 LGA 1151 Processor
9th Gen Intel® Core™ i3 LGA 1151 Processor
8th Gen Intel® Core™ i7 LGA 1151 Processor
8th Gen Intel® Core™ i5 LGA 1151 Processor
8th Gen Intel® Core™ i3 LGA 1151 Processor
8th Gen Intel® Pentium® LGA 1151 Processor
8th Gen Intel® Celeron® LGA 1151 Processor
Maximum CPU TDP (Thermal Design Power) : 95Watt

MEMORY
Support Dual Channel DDR4 1866/ 2133/ 2400/ 2666 MHz
2 x DDR4 DIMM Memory Slot
Max. Supports up to 32GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module

STORAGE
4 x SATA III Connectors (6GB/s)
1 x M.2 (M Key) Connector(6Gb/s): Support SATA SSD

LAN
Realtek RTL8111H - 10/100/1000Mb/s Controller
Support Super LAN Surge Protection

USB
6 x USB 3.1 Gen1 Ports (4 on rear I/Os and 2 via internal header)
6 x USB 2.0 Ports (2 on rear I/Os and 4 via internal header)

EXPANSION SLOT
1 x PCI-E 3.0 x16 Slot
11 x PCI-E 3.0 x1 Slots

H/W MONITORING
CPU / System Temperature Monitoring
CPU / System Fan Monitoring
System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring

DIMENSION
ATX Form Factor Dimension: 30.5cm x 21.0cm ( W x L )

OS SUPPORT
Supports Windows 10(64bit) / 11(64bit)

ACCESSORIES
2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x User Manual

Gambar produk
