BIOSTAR Motherboard B660GTN Intel B660 LGA1700 DDR4

Detail BIOSTAR Motherboard B660GTN Intel B660 LGA1700 DDR4

erima kasih Sudah berkunjung di Kurnia Abadi Semesta.
Demi kenyamanan bersama terkait harga, stock, warna, dll, harap konfirmasi terlebih dahulu sebelum order.
Terima kasih

B660GTN Ver. 5.x
Socket : 1700

Supports 12th Generation Intel Core™ Processor
Intel B660 single chip architecture
Supports 2-DIMM DDR4- 1866/ 2133/ 2400/ 2666/ 2800/ 2933/ 3200/ 3600(OC)/ 3800(OC)/ 4000(OC)/ 4133(OC)/4333(OC)/ 5000+(OC) up to 64 GB Memory
Supports PCIe 5.0
Supports PCIe M.2 4.0 (64Gb/s)
Supports Intel Optane Technology
Supports HDMI 2.0
Supports 2.5 GbE LAN
Supports USB 3.2 Gen2
Support WiFi 6 & 6E module (No WiFi card included)

Chipset Intel B660
CPU SUPPORT Support for 12th Generation Intel Core™ i9/ i7/ i5/ i3 processors and Intel Pentium processors/Intel Celeron processors in the LGA1700 package
MEMORY Supports Dual Channel DDR4-1866/ 2133/ 2400/ 2666/2800/2933/3200/3600(OC)/3800(OC)/4000(OC)/ 4133(OC)/4300(OC)/5000+(OC)
2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/ 8/ 16/ 32GB DDR4 module
Support Intel Extreme Memory Profile (XMP) memory modules
STORAGE 4 x SATA III Connector (6Gb/s) : Supports AHCI & Intel Rapid Storage Technology
1 x M.2 (M Key) Socket (M2_PCIEG4_64G):
Supports M.2 Type 2280 SSD module
Supports PCI-E 4.0 x4 (64Gb/s)
AUDIO CODEC ALC1220
7.1 Channels, High Definition Audio, Hi-Fi(Front + Rear)
INTERNAL I/O 4 x SATA III Connectors (6Gb/s)
1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel CNVi
1 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x CPU water cooling connector (CPU_OPT)
DIMENSION Mini ITX Form Factor Dimension: 17cm x 17cm ( W x L )
BUNDLE SOFTWARE Racing GT Utility
BullGuard
FEATURES VIVID LED DJ
BIO-FLASHER
A.I FAN
RACING GT Utility

Gambar produk
