Bafo EZ konektor rj45 cat5e/cat6 pass through 50um gold pin

Merek: Bafo | Lihat selengkapnya produk Komputer & Aksesoris dari Bafo
Komputer & Aksesoris > Komponen Network > Kabel Network & Konektor > Bafo EZ konektor rj45 cat5e/cat6 pass through 50um gold pin
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail Bafo EZ konektor rj45 cat5e/cat6 pass through 50um gold pin

PLUG SPECIFICATIONS
*UL 1863 No. 137614(DUXR2), complies with FCC part 68 subpart F standards.
Electrical Test 1..Dielectric Withstanding Voltage test 1000V/DC
2. Insulation Resistance: >500MΩ
3. Contact Resistance:<20MΩ

Gold Plate Inspection

(Per MIL-G-45204C)
1. TYPE II (99% pure gold minimum)
2. Grade C+(KNOOP HARDNESS RANGE 130~250)
3. Class 1(50 microinches minimum thickness)
Mechanical 1. Cable-to-plug tensile strength-20LBs(89N) min.
2. Durability:2000 mating cycles.
Material & Finish 1. Housing Material: Polycarbonate(PC.)
94V-2(For UL 1863 DUXR2)
2. Contact blade: Phosphor Bronze
a. High strength copper alloy [JIS C5191R-H(PBR-2)].
b.100 microinches nickel under plated & Gold selected.

Operating Temperature:-40 ℃~+125℃
harga per 100pcs
