ARKTEK H61M EL Alpha Force Intel LGA1155 H61 DDR3 Motherboard

Detail ARKTEK H61M EL Alpha Force Intel LGA1155 H61 DDR3 Motherboard

SPECIFICATION:

Intel H61
+ Model: AK-H61M EL
+ Socket: LGA1155
+ Chipset: Intel H61
+ Memory Support: Dual Channel DDR3

Processor Intel® Socket 1155 for Intel Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Chipset Intel H61 Chipset
On-Board Graphics Intel® Graphics Media Accelerator X4500 HD
Memory DDR3 1600/ 1333/1066 memory
DIMM 2 x Memory Slots
LAN Realtek 8105E/8111E 100/1000 Mbps (Optional)
Audio Realtek 6 Channel Audio Codec
SATA 4 x SATA port
Back Panel I/O Ports 1 x VGA port 1 x HDMI port 6 x USB 2.0 port 1 x LAN jack 3 x Audio jack
Form Factor Micro-ATX (18.5 x 16.8 cm)
Slots 1 x PCI Express x16 slot 1 x PCI E x1 slot
Mounting 6 mounting holes
Accessories 1 x SATA cable 1 x I/O Backboard 1 x User Manual 1 x Driver CD
Remark All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. PCB color and bundled software versions are subject to change without notice. Brand and product names mentioned are trademarks of their respective companies.
ON-Board Pinheaders / Connectors 2 x USB 2.0 pinheader supports additional 4 USB 2.0 ports 1 x Front Panel Audio pinheader
