ARKTEK H110M EG Alpha Force Intel LGA1151 H110 DDR4 Motherboard

Detail ARKTEK H110M EG Alpha Force Intel LGA1151 H110 DDR4 Motherboard

SPECIFICATION:
+ Model: AK-H110M EG
+ Socket: LGA1151
+ Chipset: Intel H110
+ Memory Support: Dual Channel DDR4
CPU Support CPU Support: Intel® Socket 1151 for 7th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® 14 nm CPU
Chipset Chipset: Intel H110 Chipset
On-Board Graphics Integrated Graphics Processor-Intel® HD Graphics support
Memory DDR4 2133 MHz (Max. Supports up to 16GB Memory)
DIMM 2 x Memory Slots
LAN On board Realtek® RTL8105E 10/100 Mbps adaptive network card interface
Audio Chip integrated by Realtek 661 on board, Supports 6-channel audio-out
SATA 4 x SATA port
Real I/O 1 x PS/2 mouse port 1 x PS/2 keyboard port 1 x VGA port 1 x HDMI port 2 x USB 2.0 port 2 x USB 3.0 port 1 x LAN jack 3 x Audio jack
Internal I/O 2 x USB 2.0 header supports additional 4 USB 2.0 ports 1 x USB 3.0 header supports additional 2 USB 3.0 ports 1 x Front Panel Audio header
Expansion Slots 1 x PCI Express x16 slot
Form Factor Micro-ATX (19.7 x 17 cm)
OS Support Support Windows 7 / 8 / 8.1 / 10(x64)
Mounting 6 mounting holes
Accessories 1 x SATA cable 1 x I/O Backboard 1 x User Manual 1 x Driver CD
Remark All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. PCB color and bundled software versions are subject to change without notice. Brand and product names mentioned are trademarks of their respective companies.
