1GE+2.4G wifi (300M) XPON ONU HSGQ-X100W2

Detail 1GE+2.4G wifi (300M) XPON ONU HSGQ-X100W2

1x 10/100/1000M Ethernet interface(RJ45)
1x GPON/EPON adaptive interface
2.4G WIFI

Key Features :

● Support device - based rate limitation and bandwidth control
● ln compliant with IEEE802.3ah and ITU-T G.984.x Standard
● Wi - Fi series meet 802.11 n/b/g technical standards
● Up to 20KM transmission Distance
● Support data encryption, group broadcasting, port Vlan separation ,etc.
● Support Dynamic Bandwidth Allocation (DBA)
● Support ONU auto - discovery/Link detection/remote upgrade of software;
● Support port VLAN configuration
● Support power - off alarm function ,easy for link problem detection
● Support broadcasting storm resistance function
● Support port binding
● Support port forwarding
● Support ACL to configure data packet filter flexibly
● Specialized design for system breakdown prevention to maintain stable syste
● Support software online upgrading
● Support TRO69 for ACS(Auto Config Server)
● Support PPPoE/DHCP Server/NAT

WIFl Features(2.4G) :

● Wi-Fi Specification IEEE 802.11n compliant,2.4 GHz
● FulIEEE 802.11b/glegacy compatibility with enhanced performance
● Two-stream spatial multiplexing up to300 Mbps PHY data rates
● Support multi-SSID (Maximum 4 SSID)
● Support automatic channel selection
● Support hide SSID
● Support wireless security of 64/128 bit WEP,802.1x,WPA and wPA2

Technical Parameter

User interface 1 *10/100/1000MRJ45
2.4GWiFi

PON EPON&GPON mode adaptive lnterface Type:SC-UPC/SC-APC
Transmission distance: 20KM
GPON: upstream 1.25Gbps /downstream 2.5Gbps
Transmitting optical power: 0.5~5dBm
optical receive sensitivity:≥-7~-28dBm


EPON: upstream 1.25Gbps /downstream 1.25Gbps
Transmitting optical power: 0~4dBm
Optical receiver sensitivity:≥-7~-27dBm
Ethernet
1*10/100/1000Mauto-negotiation
Full/half duplex mode
RJ45 connector
Auto MDI/MDI-X100m distance
Size 105mm(L)×85mm(W) × 25mm(H)
Environment
Operating temperature:0℃～60℃
Operating humidity:10%～85% non-condensing
