Detail XL6009 Auto Boost Buck Adjustable Step Up Step Down DC to DC converter module
Hi #RekanEasyWare ...EasyWare Part#: EP000750
SPESIFIKASI :
- Model Specification: DSN6000AUD Automatic Buck module
- Module Properties: Non- isolated boost (BOOST)
- Rectification: Non- Synchronous Rectification
- Input Range: 3.8V - 32V
- Output Range: 1.25V - 35V
- Input Current: 3A ( max ) , no-load 18mA (5V input , 8V output , no-load is less than 18mA. Higher the voltage , the greater the load current . )
- Conversion efficiency: <94% ( greater the pressure , the lower the efficiency )
- Switching frequency: 400KHz
- Output Ripple: 50mV ( the higher the voltage , the greater the current , the greater the ripple )
- Load Regulation: ± 0.5%
- Voltage Regulation: ± 0.5%
- Operating Temperature: -40 - +85
KELENGKAPAN :
- 1pcs XL6009 Auto Buck Boost DC to DC Step Up Down
