Webcam CCTV DS-UC2 Black Hikvision

Detail Webcam CCTV DS-UC2 Black Hikvision

Specification

Camera

Image Sensor: 4 MP CMOS
Signal System: PAL/NTSC

Frame Rate
MJPG：
2560 × 1440 @ 30 fps/25 fps
1920 × 1080 @ 60 fps/50 fps/30 fps/25 fps
1280 × 960 @ 60 fps/50 fps/30 fps/25 fps
1280 × 720 @ 60 fps/50 fps/30 fps/25 fps
640 × 480 @ 60 fps/50 fps/30 fps/25 fps
YUV2：
1920 × 1080 @ 5 fps
1280 × 960 @ 5 fps
1280 × 720 @ 10 fps
640 × 480 @ 30 fps

Resolution: 2560 (H) × 1440 (V)
Min. Illumination: 0.1 Lux @ (F1.2, AGC ON)
Shutter Time: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Lens: 3.6 mm fixed focal lens
Field of View: horizontal FOV: 80°, vertical FOV: 50°, diagonal FOV: 88°
Lens Mount: M8
Day & Night: 24/7 Color Imaging
Angle Adjustment: pan: 0° to 360°; tilt: 0° to 35°; ratation: 0°
Digital Zoom: 1.5 ×
Cable Length: 2 m
Depth of Field: 0.1 m to ∞


Wide Dynamic Range (WDR): Digital WDR
White Balance: Auto

Audio

Audio Sampling Rate: 16 kHz

Interface

Video Output: USB 2.0
Operating System: Windows XP/7/10, Android, Linux, MAC OS
Built-in Microphone: 2 built-in microphones, picking up sounds in the radius up to 5 meters
Indicator: White: Normally Working

General

Operating Conditions: -10°C to 40°C (-40°F to 104°F), Humidity: 90% or less (non-condensing)
Power Supply: DC 5V ± 5% (USB)
Consumption: 2.5 W MAX
Dimension: 120 mm × 27.9 mm × 25.6 mm (4.72" × 1.10" × 1.01")
Weight: Approx. 147 g (0.32 lb.)
