Warm WA-TB12 Tone Beast - Single-Channel American Mic Pre

Detail Warm WA-TB12 Tone Beast - Single-Channel American Mic Pre

CONSOLE-GRADE MIC PRE FOR SHAPING YOUR SOUND WITH USER SWITCHABLE, DUAL-TONE CONTROL AND ADDED EXTRA PUNCH

Technical Specifications
71DB OF GAIN
TRANSFORMER SELECTION PROVIDES BOTH STEEL AND 50% NICKEL CINEMAG OUTPUT TRANSFORMERS FOR VARYING CHARACTER
TRANSFORMER BYPASS SWITCH ALLOWS FOR REMOVAL OF THE OUTPUT TRANSFORMER FROM THE CIRCUIT
DISCRETE OPAMP SELECTION ALLOWS FOR CHOOSING BETWEEN A 1731(VINTAGE) AND 918(CLEANER) STYLE OPAMP. THESE ARE SOCKETED/SWAPPABLE WITH YOUR CHOICE OF 2520 6 PIN FOOTPRINT OPAMPS
IMPEDANCE SWITCH LABELED TONE TO SWITCH BETWEEN 150 AND 600 OHMS INPUT IMPEDANCE
2 MEG OHM TRUE HI-Z INPUT ON FRONT PANEL SENDS INSTRUMENT SIGNAL THROUGH ENTIRE CIRCUIT INCLUDING BOTH CINEMAG TRANSFORMERS AND THE DISCRETE OPAMPS. GREAT FOR GUITARS, BASS, KEYBOARDS AND OTHER INSTRUMENTS THAT HAVE A 1/4″ OUTPUT JACK
80HZ HIPASS FILTER
POLARITY REVERSE
UTILIZES PREMIUM GRADE CINEMAG USA TRANSFORMERS
+48V PHANTOM POWER
OUTPUT ATTENUATION ALLOWS FOR SATURATION FLEXIBILITY OF BOTH OPAMPS AND TRANSFORMERS
¼" INSERT FOR THE USE OF INLINE COMPRESSORS, EQ'S ETC
BALANCED XLR MIC (FRONT AND BACK), BALANCED TRS LINE, AND ¼" UNBALANCED INSTRUMENT INPUTS
BALANCED XLR AND TRS OUTPUTS
-20DB PAD
LED VU METER
19" RACKMOUNTABLE
SWITCHABLE 115/230 VOLT IEC POWER INLET.
CAPACITOR SELECTION BETWEEN TANTALUM AND ELECTROLYTIC FOR DIFFERENT CHARACTERS
