Detail Warm WA-2A WA2A Tube Optical Compressor

Authentic reproduction of the most revered compressor and leveling amplifier in recording history

Technical Specifications
'2A STYLE, TRANSFORMER BALANCED, HIGH VOLTAGE, OPTO TUBE COMPRESSOR​.
UTILIZES PREMIUM GRADE INPUT AND OUTPUT CINEMAG USA TRANSFORMERS.
USA MADE KENETEK OPTO-CELL ATTENUATOR T4' STYLE MODULE. SOCKETED TO ALLOW RETRO-FITTING WITH OTHER OPTO-CELLS.
PREMIUM TUBES. 2X 12AX7, 1X 12BH7, 1X 6AQ5 OR 6P1.
FULLY DISCRETE SIGNAL PATH.
VARIABLE PRE-EMPHASIS, ALLOWS FOR COMPRESSION HIPASS FILTERING (TONE CONTROL).
STEREO-LINK CAPABLE VIA TRS CONNECTOR.
INPUT IMPEDANCE - 600 OHMS, BRIDGES-T CONTROL (FLOATING).
XLR AND TRS BALANCED LINE LEVEL OUTPUTS - 600 OHMS IMPEDANCE.
XLR AND TRS BALANCED LINE LEVEL INPUTS - 600 OHMS IMPEDANCE.
FREQUENCY RESPONSE +/- 1 DB, 15 HZ TO 20KHZ.
GAIN 40 DB ±1DB.
INPUT LEVEL +16 DB MAXIMUM.
OUTPUT LEVEL +10 DB NOMINAL, +16 DB MAXIMUM.
DISTORTION LESS THAN 0.1% THD AT ±10 DBM.
NOISE = -74DB.
ATTACK TIME - 10 MILLISECONDS.
RELEASE TIME - 0.06 SECONDS FOR 50% RELEASE - 0.5 TO 5 SECONDS FOR COMPLETE RELEASE.
METER DISPLAYS BOTH DB GAIN REDUCTION AND DB OUTPUT.
POWER - 115/230 VOLTS (SWITCHABLE), 50/60 HZ.
DIMENSIONS - 19" RACKMOUNT CHASSIS, 2U. 19" X 7" X 3.5".
