Walkie Talkie HT ICOM IC-V86 IC V86

Detail Walkie Talkie HT ICOM IC-V86 IC V86

PERHATIAN
PEMBELI DARI LUAR JAWA TIDAK BISA MENGGUNAKAN JnT PASTI DITOLAK KARENA ADA BATERAI PASTI DITOLAK.

The IC-V86 gives you more audio, more RF power, more coverage and more battery capacity in a compact, MIL-STD portable. With 1.5W of receive audio power and a new chassis design, the IC-V86 enables users to hear incoming signals in loud, noisy environments. The IC-V86 expands users radios coverage with 7W of RF output power and the new 2250mAh Li-Ion battery pack provides longer operational capabilities.

Output Power: 7.0/5.5/2.5/0.5 Watts
TX/RX Frequencies: 136-174 MHz
Channels: 207 (200 regular, 6 scan edges, 1 call)
Waterproof Rating: IP54

Rugged Construction

The IC-V86 tested to and passed MIL-STD-810 C, D, E, F & G environmental tests. Also meets equivalent MIL-STD-810-C, -D, -E and -F.


SPECFICATIONS
GENERAL
Frequency Coverage : VHF TX/RX 136.000 – 173.995 Khz
*Guaranteed range 144.000 – 148.000 Khz
Type of emissions : F2D/F3E (FM)
No. of memory Ch. : 207 (inc 6 scan edges and 1 call)
Operating Temperature: -2 0OC ~ +60OC
Frequency stability : + 2.5 ppm at 25OC
Operating Voltage : : 7.2 V DC
Antenna Impedance : 50 Ω (BNC)
Dimension (WxHxD) : 58.6(W) x 112(H) x 30 (D)mm
Weight (approx.) : 140 g (w/o battery)
310 g (w/BP-298 and Ant)

TRANSMITTER
Output power (at 7.2V) : Ext. Hi:7/Hi:5.5/Mid:2.5/Low:0.5W
Max. freq. devition : +5.0Khz(wide)/+2.5Khz(narrow)
Spurious emissions ; Less than -60db
External microphone : 3-conductor 2.5 (d0mm?2.2 KΩ
Connector

RECEIVER
Sensitivity : -124 dBm(at 12 dB SINAD)
Squelch sensitivity : -126 dBM typical (threshold)
Selectivity : 75dB(Wide)/70dB(Narrow) typical
Intermodulation : 65dB typical
Spurious and image : -75dB typical
Rejection
Audio output power : 1.5W typ.
(at 10% distortion)
External speaker : 3-conductor 3.5(d) mm

Perlengkapan Standart ;
- 1 Unit HT
- 1 Antena
- 1 Baterai 2250mA (BP-298)
- 1 Beltclip
- 1 Desktop charger (BC-240)
- 1 Adaptor Charger (BC-242)
- 1 Manual

Gambar produk
