UPS Prolink 1200 VA

Detail UPS Prolink 1200 VA

UPS 120

UPS Prolink 1200 VA

Detail Spesifikasi :

Ouput Power Capacity : 1200VA / Up to 840 Watt

Output Power Voltage : 220V AC (rating), 220VAC 17~22% (Battery Mode) Freq: 50HZ 1Hz (Battery Mode)

Input Power Voltage : 140 ~ 285V, Frequency Range 40Hz - 70Hz, Phase : Single + GND

Transfer Time : 2ms Typical

Back-Up Time : 8~40 Minutes (depending on load), 90% Capacity after 8 hrs Charging Time

Battery Type : Maintenance Free-Sealed Lead-Acid Battery with Suspended Electrolyte (Leakproof

Dataline Protection : RJ-11 Mode/Fax/DSL Protection (Two Wire Single Line)

Power Factor : Up to 0.7

Indicator LED : Normal Mode, Back-Up Mode, Charging Mode

Input Interface : 1x IEC 320 C13

Output Interface : 3x IEC 320 C13 (Battery), 1x Standard AC Outlet (Bypass Outlets)

Software Support : Available

Software Interface : COM/Serial Port

Protection Avaibility : Short Circuit Protection, Surge Protection, Overload & Temperature Protection, AVR

Other Features : Intelligent Battery Management, Short Circuit Software protection (CPU)

Dimension (WHD) : 44.5(W) x 19.5(H) x 30(D) mm

Weight : 13 Kg

Others : Built-In Automatic Voltage Regulation (AVR)

Gambar produk
