Ultrasonic Flow Meter TUF2000H Liquid Tester Meter 50-700mm TUF-2000H

Detail Ultrasonic Flow Meter TUF2000H Liquid Tester Meter 50-700mm TUF-2000H

Ultrasonic Flow Meter TUF2000H Liquid Tester Meter 50-700mm TUF-2000H

Ready Stok langsung order saja
100% unit BARU
-----
Garansi quality CHECK sebelum kirim
GARANSI toko 1BULAN
-----
Dikirim dari JOGJA
Garansi packing AMAN (GRATIS bubblewrap/kardus)

Flow Meter adalah alat untuk mengukur laju aliran atau jumlah suatu fluida yang bergerak mengalir. Jenis cairan yang diukur oleh flow meter bisa berbagai macam cairan seperti air minum, air limbah, air lumpur, susu, cairan kimia, air gula, alkohol, oli dll

Ultrasonic Flow Meter TUF2000H mengukur laju aliran cairan dengan metode ultrasonik. Dilengkapi dengan transducer TM-1 untuk diameter pipa 50mm-700mm

Specifications:
- Linearity: 0.5%
- Repeatability:0.2%
- Accuracy: Better than 1% for velocity above 0.2m/s
- Response Time: 0-999 second, user-configurable
- Flow Range: 32m/s
- Measuring Pipe Size: DN50-700mm
- Units: English (U.S.) or metric
- Totalizer: 7-digit totalizer for net, positive and negative flow respectively
- Liquid Types: Any single uniform liquid which can transmit ultrasonic
- Security: Setup values Modification Lockout. Access code needs unlocking
- Display: 416 character
- Communication Interface: RS-232 interface. 75-57600bps, compatible with Fuji ultrasonic flowmeter and other UFM on enquiry.
- Transducers: Model TM-1 for standard, other models optional
- Transducer Cable: Standard 5m x2 or can be extended to 10m x2
- Power Supply: 3 AAA built-in Ni-MH batteries (for over 12 hours of operation). 100V-240VAC adapter
- Data Logger: Built-in data logger can store over 2000 lines of data
- Manual Totalizer: 7 digit, calibrating by key
- Housing Material: Flaming retarding ABS
- Size: 2009333mm
- Handset Weight: 400g with batteries

------
Terimakasih sudah mengunjungi toko kami
Kita tunggu orderannya ya

Gambar produk
