Detail UBNT UBIQUITI POE-24-12W / POE 24V 0.5A POE Adaptor

SPECIFICATION:

Model


POE-24-12W

Dimensions


87 x 44 x 29 mm

(3.43 x 1.73 x 1.14")

Weight


92 g (3.25 g)

Output Voltage


24VDC @ 0.5A

LAN Activity Indicator


No

Gigabit LAN Port


No

Remote Reset Capability


Yes

Reset Button


Yes

Rated Voltage


100-240VAC @ 50/60Hz

Input Current


0.3A @ 120VAC,

0.2A @ 240VAC

Inrush Current


<30A Peak @ 120VAC,

<60A Peak @ 230VAC

Efficiency


75+%

Output Ripple


1% Max.

Switching Frequency


50 kHz

Line Regulation


≤ 3%

Load Regulation


≤ 5%

2-Pair Powering


Pins 4, 5 (+) and Pins 7, 8 (-)

4-Pair Powering


–

Operating Temperature


0 to 40° C (32 to 104° F)

Storage Temperature


-30 to 70°C (-22 to 158° F)

Operating Humidity


35 to 95% Noncondensing

AC Connector


IEC-320 C6

Data IN / POE


RJ45 Shielded Socket

Surge Protection


Difference and Common Mode

Clamping Protection


11V Data, 60V Power

Max. Surge Discharge


1500A (8/20 µs) Power

Peak Pulse Current


36A (10/1000 µs) Data

Shunt Capacitance


<5 pF data

Response Time


<1 ns

Certifications


CE, FCC, IC, UL
