Switch 48 PoE (500W)
US-48-500W
Layer 2, PoE switch with (48) GbE, 802.3at PoE+ and 24V passive PoE RJ45 ports, (2) 1G SFP ports, and (2) 10G SFP+ ports.
The Switch 48 PoE 500W (US 48 PoE 500W), a fully managed switch with (48) GbE RJ45 ports, (2) 1G SFP ports, and (2) 10G SFP+ ports. Each of the switch's ports can provide either 802.3at PoE+ or configurable, 24V passive PoE to UniFi access points or other PoE devices. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(48) GbE, 802.3at PoE+ and 24V passive PoE RJ45 ports
(2) 1G SFP ports
(2) 10G SFP+ ports
500W total PoE supply
US-48-500W
Dimensions 485 x 43.7 x 374.6 mm
(19.09 x 1.72 x 14.75")
Weight 6.1 kg
(13.5 lb)
Networking Interfaces ((48) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1/10 Gbps SFP+ Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports
Management Interface (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
Total Non-Blocking Throughput 70 Gbps
Switching Capacity 140 Gbps
Forwarding Rate 104.16 Mpps
MAC Address Table 16384
Maximum Aggregations 6
Monitoring Sessions 1
Maximum VLANs 255
Power Method 100-240VAC/50-60 Hz, Universal Input
Power Supply AC/DC, Internal, 500W DC
Max. Power Consumption
Including PoE Output
Excluding PoE Output
500W
64W
LEDs Per Port
RJ45 Data Ports
SFP Data Ports
PoE, Speed/Link/Activity
Speed/Link/Activity
Sound Level*
Fan Level 0
Fan Level 1
Fan Level 2
Fan Level 3
10.7 dBr
16.2 dBr
19.3 dBr
23.6 dBr
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC
PoE+ Per Port
PoE Interfaces PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
