Ubiquiti UXG-PRO Next-Generation Gateway Pro

Detail Ubiquiti UXG-PRO Next-Generation Gateway Pro

Features:
1.7 GHz quad-core processor
(2) WAN ports (GbE RJ45 and 10G SFP+) with failover support
(2) LAN ports (GbE RJ45 and 10G SFP+)
Enterprise-class DPI, IPS/IDS, and layered firewall configuration
Power redundancy when connected to the UniFi SmartPower RPS (sold separately)
SmartPower outlet (125VAC/2A) for an external modem
1U-sized, rack-mountable device
Mechanical
Dimensions 442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24")
Weight 3.42 kg (7.54 lb)
Enclosure materials Front panel: aluminum CNC
Top cover/base: SGCC steel
Hardware
Processor Quad-core ARM® Cortex®-A57 at 1.7 GHz
Memory information 2 GB DDR4
Management interface Ethernet
Networking interface LAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port
WAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port
LCM display (1) 1.3" touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: firmware upgrading
Button Factory reset
Power method
US
(1) Universal AC input, 125VAC, 2.7A max., 60 Hz
(1) RPS DC input, 11.5VDC, 2.87A
Worldwide
(1) Universal AC input, 200-240VAC, 1.7A max., 50/60 Hz
(1) RPS DC input, 11.5VDC, 2.87A
Power supply AC/DC, internal, 50W
Max. power consumption 30W
ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV
Operating temperature -10 to 40° C (14 to 104° F)
Operating humidity 5 - 95% noncondensing
Certifications CE, FCC, IC
LEDs
AC outlet/ RPS Blue
Ethernet Green/amber
SFP+ White/green
