UBIQUITI USW-Pro-48-POE Gen2

Detail UBIQUITI USW-Pro-48-POE Gen2

USW-Pro-48-POE

The USW-Pro-48-POE is a configurable Gigabit Layer2 and Layer3 switch with auto-sensing 802.3at PoE+ and 802.3bt PoE++. Forty PoE+ and eight PoE++ RJ45 ethernet ports have total 600W PoE budget, and four SFP+ ports offer 10Gbps uplink options. Near-silent cooling and a 1.3" touch LCM.

Specifications
USW-Pro-48-POE

Dimensions
442.4 x 399.6 x 43.7 mm
(17.42 x 15.73 x 1.72")

Weight
6.25 kg (13.78 lb)

With Rackmount Brackets 6.34 kg (13.98 lb)
Interfaces

Networking (48) 10/100/1000 RJ45 Ports
(4) 1/10G SFP+ Ethernet Ports
Management Ethernet In-Band
Power Method

Universal Input 100-240VAC/50-60 Hz
USP RPS DC Input 52VDC, 11.54A; 11.5VDC, 5.22A
Power Supply

AC/DC, Internal, 660W

Supported Voltage Range

100 to 240VAC

Max. Power Consumption
(Excluding PoE Output)

60W

LEDs

System Status
RJ45 Data Ports PoE; Speed/Link/Activity
SFP+ Data Ports Link/Activity
ESD/EMP Protection

Air: ± 16 kV, Contact: ± 12 kV

Shock and Vibration

ETSI300-019-1.4 Standard

Operating Temperature

-5 to 40° C (23 to 104° F)

Operating Humidity

10 to 90% Noncondensing

Certifications

CE, FCC, IC

Sound Level*
25% PoE Load, 25° C Room Temperature
0.9 dBr
50% PoE Load, 25° C Room Temperature
7.3 dBr
100% PoE Load, 40° C
22.5 dBr
* Background noise level: 27.5 dBa
PoE
PoE Interfaces
Ports 1-40 POE+ IEEE 802.3af/at
(pins 1, 2+; 3, 6-)
Ports 41-48 60W PoE++ IEEE 802.3bt
(Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-)
Max. PoE Wattage per Port by PSE

802.3at 32W
802.3bt 64W
Voltage Range 802.3af Mode
44-57V
Voltage Range 802.3at/bt Mode
50-57V
