Detail Ubiquiti Unifi U6-IW | Unifi6 in Wall |Access Point In-Wall

Ubiquiti U6-UW | Unifi6 In Wall

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Wall-mounted WiFi 6 access point with a built-in PoE switch.

Features:

WiFi 6 support (2.4/5 GHz bands)
5.3 Gbps aggregate throughput rate
(1) GbE RJ45 port (PoE In)
(4) GbE RJ45 ports, including one that supports PoE output

Mechanical Dimensions
139.66 x 96 x 31.19 mm (5.5 x 3.78 x 1.28")
Weight : 460 g (1.01 lb)
Enclosure materials : Plastic, aluminum

Mount material : Aluminum

Hardware
Management interfaces
Ethernet
Bluetooth
Networking interfaces
(1) Data-in: 1GbE RJ45 port
(4) Data-out: 1GbE RJ45 ports

PoE interfaces
(1) PoE in (PoE output not used)
(1) PoE out (requires a PoE+ switch)

Button
Factory reset

LED
White/blue

Power method
PoE

Power supply
UniFi PoE switch
48V, 0.5A PoE adapter (optional)

Max. power consumption
Excluding PoE output: 13.5W

Max PoE wattage per port by PSE
15.4W*
*Requires a PoE+ switch

Voltage range PoE mode
44 to 57VDC

Max. TX power
2.4 GHz 22 dBm
5 GHz 26 dBm
MIMO
2.4 GHz 2 x 2 (UL MU-MIMO)
5 GHz 4 x 4 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz 573.5 Mbps
5 GHz 4.8 Gbps
Antenna gain
2.4 GHz 5 dBi
5 GHz 5.9 dBi
Operating temperature
-30 to 60° C (-22 to 140° F)

Operating humidity
5 - 95% noncondensing

Certifications
CE, FCC, IC

Software
WiFi standards
802.11a/b/g
WiFi 4/WiFi 5/WiFi 6

Wireless security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID : 8 per radio
VLAN : 802.1Q
Advanced QoS
Per-user rate limiting

Guest traffic isolation
Supported

Concurrent clients : 300+
Zero-wait DFS : Yes

Supported Data Rates
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b
1, 2, 5.5, 11 Mbps

802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4)
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)

802.11ac (WiFi 5)
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (WiFi 6)
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

Gambar produk

Ubiquiti Unifi U6-IW | Unifi6 in Wall |Access Point In-Wall
