Ubiquiti UniFi Switch 48 USW-48

Detail Ubiquiti UniFi Switch 48 USW-48

ubiquiti switch USW-48

Layer 2 switch with (48) GbE RJ45 ports and (4) 1G SFP ports.

The Switch 48 (USW 48) is a fully managed, fanless switch with (48) GbE RJ45 ports and (4) 1G SFP ports. The versatile USW 48 provides Gigabit links to Ethernet devices while also supplying Gigabit fiber uplink options fit for an enterprise network. The switch also offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate), and features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

(1) 1.3" LCM color touchscreen with AR switch management
(48) GbE RJ45 ports
(4) 1G SFP ports
Fanless, silent cooling

Mechanical
Dimensions
442.4 x 285 x 43.7mm (17.42 x 11.22 x 1.72")

Weight
Without Mount: 3.9 kg (8.6 lb)

With Mount: 3.99 kg (8.8 lb)

Enclosure Characteristics
SGCC Steel

Hardware
Total Non-Blocking Line Rate
52 Gbps

Max. Power Consumption
40W

Forwarding Rate
77.376 Mpps

Power Method
Universal AC Input: 100-240VAC, 50/60 Hz

Power Supply
AC/DC, Internal, 60W

Supported Voltage Range
100 - 240VAC

Networking Interfaces
(48) 10/100/1000 Mbps Ethernet RJ45 Ports

(4) 1 Gbps SFP Ports

Management Interface
Ethernet In-Band

Modes
SMB Layer 2 Gigabit Ethernet Switch

Operating Temperature
-15 to 40° C (5 to 104° F)

Operating Humidity
10 - 90% Noncondensing

Certifications
CE, FCC, IC

LEDs
System
(1) Bootup Animation: Bootup in Progress

Firmware Upgrade Icon: Firmware Upgrading

Steady White: Factory Defaults, Awaiting Adoption

Steady Blue: Device is Adopted

Ethernet
Green: 1G, Amber: 10/100 Mbps

SFP
Green: 1G
