UBIQUITI UniFi 6 Professional U6-Pro-US Access Point

Detail UBIQUITI UniFi 6 Professional U6-Pro-US Access Point

High-performance, ceiling-mounted WiFi 6 access point designed for large offices.

Features:

WiFi 6 support (2.4/5 GHz bands)
5.3 Gbps aggregate throughput rate
(1) GbE RJ45 port (PoE In)

SPECIFICATION :
Mechanical
Dimensions Ø197 x 35 mm (Ø7.76 x 1.38")
Weight Without mount: 460 g (1.01 lb)
With mount: 600 g (1.32 lb)
Enclosure material Plastic
Mounting material SGCC steel
Weatherproofing IP54
Hardware
Management interfaces Ethernet
Bluetooth
Networking interface (1) GbE RJ45 port
Button Factory reset
LED* White/blue
*Due to chip supply shortages, the U6 AP's LED has been limited to only white and blue color modes.
Power method PoE
Power supply UniFi PoE switch
48V, 0.5A PoE adapter (not included)
Supported voltage range 44—57V DC
Max. power consumption 13W
Max. TX power
2.4 GHz
5 GHz
22 dBm
26 dBm
MIMO
2.4 GHz
5 GHz
2 x 2 (UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz
573.5 Mbps
4.8 Gbps
Antenna gain
2.4 GHz
5 GHz
4 dBi
6 dBi
Mounting Wall/ceiling (included)
Operating temperature -30 to 60° C (-22 to 140° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Zero wait DFS Yes*
*Supported with upcoming firmware versions
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
