UBIQUITI UniFi 6 Lite U6-Lite-US Access Point

Detail UBIQUITI UniFi 6 Lite U6-Lite-US Access Point

SPECIFICATION:
Mechanical
Dimensions Ø160 x 32.65 mm (Ø6.3 x 1.3")
Weight Without mount: 300 g (10.6 oz)
With mount: 315 g (11.1 oz)
Enclosure materials Polycarbonate, aluminum
Mounting materials Polycarbonate, SGCC Steel
Hardware
Management interfaces Ethernet
Bluetooth
Networking interface (1) GbE RJ45 port
Button Factory reset
LED* White/blue
*Due to chip supply shortages, the U6 Lite's LED has been limited to only white and blue color modes.
Power method PoE, passive PoE (48V)
Power supply PoE
48V, 0.32A PoE adapter (optional)
Supported voltage range 44 to 57VDC
Max. power consumption 12W
Max. TX power
2.4 GHz
5 GHz
23 dBm
23 dBm
MIMO
2.4 GHz
5 GHz
2 x 2
2 x 2
Throughput rate
2.4 GHz
5 GHz
300 Mbps
1201 Mbps
Antenna gain
2.4 GHz
5 GHz
2.8 dBi
3 dBi
Operating temperature -30 to 60° C (-22 to 140° F)
Operating humidity 5 - 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11ax (WiFi 6) 7.3 Mbps to 1.2 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80)
