Ubiquiti UISP-S | UISP Switch 8 Port Gigabit PoE Switch

Detail Ubiquiti UISP-S | UISP Switch 8 Port Gigabit PoE Switch

Deskripsi : Ubiquiti UISP-S | UISP Switch 8 Port Gigabit PoE switch

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Eight-port, Layer 2, Gigabit PoE switch designed for MicroPoP applications and building secure, high-performance networks.

Features:

Interface: (8) GbE RJ45 ports with 27V passive PoE output / (1) 1G SFP port
110W (27V) total PoE availability*, 15W/port (2-pair) / 30W/port (4-pair)
Port isolation, speed limiting, and DHCP snooping functionality
Easy Bluetooth setup with the UISP Mobile app

Mechanical
Hardware
PoE
LEDs
Dimensions 210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14")
Weight 610 g (1.34 lb)
Enclosure material Polycarbonate
Total non-blocking throughput 9 Gbps
Switching capacity 18 Gbps
Forwarding rate 13.392 Mpps
Networking interface (8) 10/100/1000 MbE RJ45 ports
(1) 1G SFP port
Managementinterface Ethernetin-band
Bluetooth BLE
Power method External AC/DC adapter
Power supply 27VDC, 4.4A power adapter (included)
Supported voltage range 24 - 28VDC
Max. power consumption 8W (excludes PoE output)
ESD/EMP protection Air: ± 15 kV, contact: ± 8 kV
Operating temperature -10 to 50° C (14 to 122° F)
Operating humidity 5 to 95% non-condensing
Certications CE, FCC, IC
PoE interface (8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-)
Max. Passive PoE wattage per port 30W/27VDC
Passive PoE voltage range 27VDC
System Status
RJ45 data ports PoE
Speed/link/activity
SFP data ports Link/activity
