Ubiquiti UBNT U-POE-AF 802.3AF PoE Injector 48V Gigabit

Detail Ubiquiti UBNT U-POE-AF 802.3AF PoE Injector 48V Gigabit

WAJIB CHAT untuk cek stok! Jumlah stok berjalan karena kami juga ada toko fisik.
============================
100% Baru dan Original

Ubiquiti UBNT U-POE-AF 802.3AF PoE Injector 48V Gigabit
*** Non Garansi ***
Produk akan ditest dulu sebelum dikirimkan untuk memastikan berfungsi dengan baik.

The 802.3af PoE Injector (U PoE AF) is designed to power 802.3af PoE devices. The U PoE AF delivers up to 15W of PoE that can be used to power the Access Point U6 Lite and other 802.3af devices. It can also provide enhanced protection against electrostatic discharge (ESD).

U-POE-af
Dimensions 86 x 46 x 33 mm
Weight 100 g
Output Voltage 48VDC @ 0.32A
LAN Activity Indicator No
Gigabit LAN Port Yes
Remote Reset Capability Yes
Reset Button No
Rated Voltage 100-240VAC @ 50/60Hz
Input Current 500mA @ 90VAC
Inrush Current <100A Peak @ 25°C
Efficiency 84.25+%
Output Ripple 200mV p-p
Switching Frequency 65 kHz
Line Regulation ≤ 3%
Load Regulation ≤ 5%
2-Pair Powering Pins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering –
Operating Temperature 0 to 40° C
(32 to 104° F)
Storage Temperature -30 to 70°C
(-22 to 158° F)
Operating Humidity 5 to 90% Noncondensing
AC Connector IEC-320 C6
Data IN / POE RJ45 Shielded Socket
Surge Protection Difference and Common Mode
Clamping Protection 11V Data, 60V Power
Max. Surge Discharge 1500A (8/20 μs) Power
Peak Pulse Current 36A (10/1000 μs) Data
Shunt Capacitance <5 pF data
Response Time <1 ns
Certifications CE, FCC, IC, UL

Gambar produk
