Ubiquiti U6-Extender
Features:

Dual-band WiFi 6 connectivity
5 GHz band (4x4 MU-MIMO and OFDMA) with up to a 4.8 Gbps throughput rate
2.4 GHz band (2x2 MU-MIMO and OFDMA) with up to a 573.5 Mbps throughput rate
Fits any standard US duplex wall outlet
Easily extends wireless coverage across large homes or offices

Mechanical
Dimensions 169.7 x 112.2 x 32.2 mm (6.68 x 4.42 x 1.27")
Weight 290 g (10.2 oz)
Enclosure material Plastic
Hardware
Management interface Bluetooth
Button Factory reset
LED* White/blue
*Due to chip supply shortages, the U6 AP's LED has been limited to only white and blue color modes.
Power method Universal AC input, 100-240VAC, 0.3A max., 50/60 Hz
Supported voltage range 110 to 240VAC
Max. power consumption 11W
Max. TX power
2.4 GHz : 22 dBm
5 GHz : 26 dBm
MIMO
2.4 GHz : 2 x 2 (UL MU-MIMO)
5 GHz : 4 x 4 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz : 573.5 Mbps
5 GHz : 4.8 Gbps
Antenna gain
2.4 GHz : 5 dBi
5 GHz : 6 dBi
Operating temperature -10 to 50° C (14 to 122° F)
Operating humidity 5 to 95% noncondensing
Certifications FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Zero wait DFS Yes
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31 , HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 3.4Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
