Ubiquiti U-POE-af PoE Injector Gigabit 48V 15W (0,32A) |U POE AF

Merek: Ubiquiti Networks | Lihat selengkapnya produk Komputer & Aksesoris dari Ubiquiti Networks
Komputer & Aksesoris > Komponen Network > Komponen Network Lainnya > Ubiquiti U-POE-af PoE Injector Gigabit 48V 15W (0,32A) |U POE AF
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:TepraStoreLihat semua produk Komputer & Aksesoris oleh TepraStore
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail Ubiquiti U-POE-af PoE Injector Gigabit 48V 15W (0,32A) |U POE AF

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

U-POE-af
Dimensions 86 x 46 x 33 mm
(3.39 x 1.81 x 1.30")
Weight 100 g
(3.53 oz)
Output Voltage 48VDC @ 0.32A
LAN Activity Indicator No
Gigabit LAN Port Yes
Remote Reset Capability Yes
Reset Button No
Rated Voltage 100-240VAC @ 50/60Hz
Input Current 500mA @ 90VAC
Inrush Current <100A Peak @ 25°C
Efficiency 84.25+%
Output Ripple 200mV p-p
Switching Frequency 65 kHz
Line Regulation ≤ 3%
Load Regulation ≤ 5%
2-Pair Powering Pins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering –
Operating Temperature 0 to 40° C
(32 to 104° F)
Storage Temperature -30 to 70°C
(-22 to 158° F)
Operating Humidity 5 to 90% Noncondensing
AC Connector IEC-320 C6
Data IN / POE RJ45 Shielded Socket
Surge Protection Difference and Common Mode
Clamping Protection 11V Data, 60V Power
Max. Surge Discharge 1500A (8/20 μs) Power
Peak Pulse Current 36A (10/1000 μs) Data
Shunt Capacitance <5 pF data
Response Time <1 ns
Certifications CE, FCC, IC, UL

Gambar produk
