Ubiquiti Rocket LTU 5GHz|LTU-Rocket 5GHz PtMP BaseStation Radio

Detail Ubiquiti Rocket LTU 5GHz|LTU-Rocket 5GHz PtMP BaseStation Radio

Ubiquiti LTU Rocket 5GHz

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

5 GHz PtMP LTU BaseStation Radio, functions in a PtMP environment using the LTU Pro, LTU Lite, or LTU LR as Clients.

Incorporating Ubiquiti’s proprietary LTU technology, the LTU-Rocket is a Point-to-MultiPoint (PtMP) 5 GHz Access Point featuring 2+ Mpps processing, proprietary RF filtering, and flexible GPS sync for superior performance. Channel width flexibility (10/20/30/40/50 MHz) allows independent TX and RX channel frequency configurations anywhere within the radio band to avoid local interference. A custom co-processor is included for future performance and feature upgrades.

Functions in a PtMP environment using the LTU-Pro, LTU-Lite for subscriber stations

TECHNICAL SPECIFICATIONS
Width x Height x Depth:
224 × 82 × 48mm (8.82 × 3.23 × 1.89")
Weight: 0.468 kg (1.03 lb)
GPS: External, Magnetic Base
Operating Frequency
5150-5250MHz
5740-5850MHz
Power
Power Supply: 24V, 1A PoE Gigabit Adapter (Included)
Power Method: Dual Passive Power over Ethernet
Max. Power Consumption: 25W
Supported Voltage Range: +18 to +54VDC*
Networking Interface
Data Port: (1) 10/100/1000 Ethernet Port
Configuration Port: (1) 10/100/1000 Ethernet Port
System
Processor: LTU IC
Maximum Throughput: 600 Mbps*
Maximum Range: 200+ km**
Encryption: 128-bit AES
Operating System: airOS F
Radio Frequency
Max TX Power: 29 dBm (Dependent on Regulatory Region)
Frequency Accuracy
± 2.5 ppm without GPS Synchronization
± 0.2 ppm with GPS Synchronization
Channel Bandwidth
10/20/30/40/50 MHz Selectable
Programmable Uplink and Downlink Duty Cycles
Environment
Operating Temperature: -40° to 55° C (-40° to 131° F)
Certifications
FCC
Mounting
airFiber X Mount (Rocket Mount Compatible)
GPS Pole Mount (Included)
